SX05GD2
Manufacturer
In-Stock:
Part Number
SX05GD2
package
Bulk
Description
SENSOR 5PSIG 0.11" .075V 6DIP
SX05GD2
Attributes
| Type | Description |
| Part Status | Obsolete |
| Features | - |
| Mounting Type | Through Hole |
| Applications | Board Mount |
| Termination Style | - |
| Operating Temperature | -40°C ~ 85°C |
| Package / Case | 6-DIP Module |
| Voltage - Supply | 12V |
| Supplier Device Package | 6-DIP |
| Pressure Type | Vented Gauge |
| Operating Pressure | 5PSI (34.47kPa) |
| Output Type | Wheatstone Bridge |
| Output | 0 mV ~ 75 mV (5V) |
| Accuracy | ±0.5% |
| Port Size | Male - 0.11" (2.67mm) Tube |
| Port Style | Barbless |
| Maximum Pressure | 20PSI (137.9kPa) |
SX05GD2
Datasheet
SX05GD2
Overview
SENSOR 5PSIG 0.11" .075V 6DIP
