eMMC Part Number Decoder: Samsung KLM vs Micron MTFC — IClee

1. Why eMMC part numbers drive everyone crazy
If you've ever tried to cross-reference an eMMC chip, you know the pain. Samsung uses KLM, Micron uses MTFC, SK Hynix uses H26M — and each has its own naming logic that reads like a cipher. Worse, the suffix digits (like -B041 vs -B001) can encode entirely different ball grid arrays, making the same "KLM8G1GETF" physically incompatible with your PCB.

2. Samsung eMMC: KLM series decoder
Samsung's eMMC naming is actually logical once you know the formula. Let's decode KLM8G1GETF-B041:

KLM  8  G  1  G  E  T  F  -  B041
│    │  │  │  │  │  │  │     └──── Customer/Revision code
│    │  │  │  │  │  │  └────────── Package type
│    │  │  │  │  │  └───────────── Generation/Version
│    │  │  │  │  └──────────────── Flash type (E = eMMC 5.0 / 5.1)
│    │  │  │  └─────────────────── Controller version
│    │  │  └────────────────────── Density unit (G = GB)
│    │  └───────────────────────── Density value
│    └──────────────────────────── Product line (KLM = eMMC, KLU = UFS)
└────────────────────────────────── Samsung Memory

3. Samsung eMMC density codes

4. Samsung eMMC temperature grades

Critical: Samsung uses the same base part number (e.g., KLM8G1GETF) across different PCB ball grids: B041 = 153-ball FBGA, B001 = 169-ball FBGA. These are not interchangeable — always verify the complete suffix when cross-referencing.

5. Samsung eMMC generation map

6. Micron eMMC: MTFC series decoder
Now let's decode MTFC16GAPALBH-IT:

MTFC  16  G  A  P  A  L  B  H  -  IT
│     │   │  │  │  │  │  │  │      └── Temperature: IT = Industrial (-40~85°C)
│     │   │  │  │  │  │  │  └───────── Revision
│     │   │  │  │  │  │  └──────────── Package material (B = BGA Pb-free)
│     │   │  │  │  │  └─────────────── Voltage (L = VCC 3.3V + VCCQ 1.8V/3.3V)
│     │   │  │  │  └────────────────── Feature set (A = Standard, G = enhanced)
│     │   │  │  └───────────────────── NAND type (P = MLC, G = TLC)
│     │   │  └──────────────────────── Generation/Die revision
│     │   └─────────────────────────── Density unit (G = GB)
│     └─────────────────────────────── Product: MTFC = eMMC
└────────────────────────────────────── Micron

7. Micron eMMC density codes

8. Micron temperature grades (more explicit than Samsung)

Micron marks temperature grade explicitly in the suffix, which makes cross-referencing much easier than Samsung's cryptic customer codes. When you see -IT, you know it's guaranteed for -40°C ~ +85°C.

9. Cross-reference: Samsung KLM ↔ Micron MTFC
Need a form-fit-function equivalent? Here's a quick map for the most common densities you'll find in the open market:

Warning: These are NOT drop-in replacements. PCB ball map, VCCQ voltage levels, and initialization sequence may differ. Always check the datasheet or do a board-level qualification before swapping.

10. 3 common mistakes when buying eMMC on the open market

1. Ignoring the suffix
Samsung's -B041 vs -B001 vs -B041-00 are all physically different chips with different ball grid arrays. An incorrect suffix means your chip won't fit the PCB footprint — even if the base part number is the same.

2. Assuming all "IT" Micron parts are the same
Micron MTFC8GAMALBH-AAT (Automotive -40~105°C) and MTFC8GAMALBH-IT (Industrial -40~85°C) are different SKUs with very different pricing. Automotive-grade is typically 30-50% more expensive.

3. Confusing eMMC 5.0 with eMMC 5.1
Samsung eMMC 5.0 (KLMxG1GE) and 5.1 (KLMAG1JE) share the same ball grid in some densities, but 5.1 adds Command Queuing and higher random read IOPS. If your host controller expects eMMC 5.1 features, a 5.0 part may function but with degraded performance.
