MX25L12845GM2I-08G Macronix 128Mbit FLASH-NOR 8-SOP, top view

MX25L12845GM2I-08G Macronix 128Mbit FLASH-NOR 8-SOP

Name: MX25L12845GM2I-08G Macronix 128Mbit FLASH-NOR 8-SOP
Brand: Macronix
SKU: MX25L12845GM2I-08G
Availability: InStock

D-U-N-S® 687211501 Inspection on request HongKong/SZ STOCK | 24h Dispatch IQC + OQC available Secure Packing

Manufacturer

Macronix

In-Stock:

10000

Part Number

MX25L12845GM2I-08G

package

Tube

Datasheet

Inspection before you pay — Quality Control → · About our hubs →

IQC · lab inspection Full QC process →

D-U-N-S® 687211501 View certificate →

ISO 9001 Vendor docs →

MX25L12845GM2I-08G

MX25L12845GM2I-08G overview

MX25L12845GM2I-08G Macronix 128Mbit FLASH-NOR 8-SOP. Key ratings: supply voltage 2.7V ~ 3.6V; operating temperature -40°C ~ 85°C (TA); clock frequency up to 120 MHz. Typical applications: Code storage and execute-in-place (XIP) for embedded systems; Firmware and boot code storage in microcontroller-based designs.

MX25L12845GM2I-08G

MX25L12845GM2I-08G specifications

Type	Description
Part Status	Active
Mounting Type	Surface Mount
Operating Temperature	-40°C ~ 85°C (TA)
Package / Case	8-SOIC (0.209", 5.30mm Width)
Voltage - Supply	2.7V ~ 3.6V
Supplier Device Package	8-SOP
Technology	FLASH - NOR
Memory Type	Non-Volatile
Memory Format	FLASH
Memory Size	128Mbit
Memory Organization	16M x 8
Memory Interface	SPI
Clock Frequency	120 MHz
Write Cycle Time - Word, Page	30µs, 750µs
Programmable	Verified

MX25L12845GM2I-08G

MX25L12845GM2I-08G features

Serial NOR Flash with 134,217,728 x 1 bit structure and Single I/O, Dual I/O and Quad I/O protocol support.
Supports clock frequency up to 133MHz and DTR (Double Transfer Rate) Mode.
Single power supply operation at 2.7 to 3.6 volt for read, erase, and program operations.
BGA-24 package.

MX25L12845GM2I-08G

MX25L12845GM2I-08G applications

Code storage and execute-in-place (XIP) for embedded systems
Firmware and boot code storage in microcontroller-based designs
Parameter and configuration data storage
Program and data storage for consumer and industrial electronics

MX25L12845GM2I-08G

MX25L12845GM2I-08G datasheet

Download
