MTFC8GAMALBH-AAT Micron Technology Inc. 64Gbit NAND Flash — managed eMMC 153-TFBGA

D-U-N-S company information Inspection options Stock listed below Incoming inspection Packaging confirmation
Manufacturer
In-Stock:
Part Number
MTFC8GAMALBH-AAT
package
Tray
Datasheet
ICLee incoming inspection
Incoming inspection View inspection options
ICLee D-U-N-S company document
D-U-N-S company information View company documents
MTFC8GAMALBH-AAT

Overview

MTFC8GAMALBH-AAT from Micron: 64Gbit NAND Flash — managed eMMC, eMMC 5.1 (HS200 / HS400), organized as 8G x 8. Supply: VCC: 2.7–3.6 V; VCCQ: 1.70–1.95 V / 2.7–3.6 V; package: 153-TFBGA. Review the cited selection conditions before requesting this exact ordering variant.

Device identity and key specifications

Capacity
64Gbit
Technology
NAND Flash — managed eMMC
Interface
eMMC 5.1 (HS200 / HS400)
Supply voltage
VCC: 2.7–3.6 V; VCCQ: 1.70–1.95 V / 2.7–3.6 V
Package
153-TFBGA
Operating temperature
-40°C ~ 105°C (TA)
Clock frequency
200 MHz (HS200 / HS400); 52 MHz (boot)
Organization
8G x 8
Catalog lifecycle
Last-time buy (catalog)

Selection and controller requirements

MTFC8GAMALBH-AAT from Micron: 64Gbit NAND Flash — managed eMMC, eMMC 5.1 (HS200 / HS400), organized as 8G x 8. Supply: VCC: 2.7–3.6 V; VCCQ: 1.70–1.95 V / 2.7–3.6 V; package: 153-TFBGA. Review the cited selection conditions before requesting this exact ordering variant.

Procurement requirements

Product-specific questions

Can MTFC8GAMALBH-AAT be wired and driven like raw NAND?

The MTFC8GAM reference describes managed eMMC storage with a controller and an eMMC interface. Core VCC and host-I/O VCCQ are separate rails, and the host must support the selected eMMC mode. Check the BGA ball map, initialization, boot-partition configuration and voltage mode; capacity alone does not establish interchangeability.

MTFC8GAM manufacturer datasheet · 1, 2

How many bytes does the listed 64Gbit capacity represent?

For MTFC8GAMALBH-AAT, 64Gbit is a bit capacity, equivalent to 8,589,934,592 bytes at eight bits per byte (K/M/G chip-density prefixes use powers of 1024). The listed organization is 8G x 8. Keep this conversion separate from interface clock rate and read/program timing when specifying the memory image or host address space.

ICLee catalog record

Which operating and ordering conditions matter for MTFC8GAMALBH-AAT?

The listed supply is VCC: 2.7–3.6 V; VCCQ: 1.70–1.95 V / 2.7–3.6 V, temperature range -40°C ~ 105°C (TA) and package 153-TFBGA. The referenced clock conditions are 200 MHz (HS200 / HS400); 52 MHz (boot). Read access, serial transfer and nonvolatile programming are separate operations; match the electrical table and exact ordering option before design-in. VCC and VCCQ are separate rails. Select the VCCQ level and power sequence required by the chosen eMMC mode; the dual-voltage listing does not mean that every high-speed mode supports both I/O voltage ranges.

ICLee catalog record

What should the RFQ for MTFC8GAMALBH-AAT include?

Request the complete MTFC8GAMALBH-AAT code, 153-TFBGA, -40°C ~ 105°C (TA) and the required quantity. Confirm carrier packaging, date/lot identification, inspection documents and blank/programmed state or image checksum where relevant in the written quotation. Availability, MOQ, unit price and dispatch timing need confirmation; a catalog quantity is not a reserved allocation.

ICLee catalog record

How should the lifecycle status of MTFC8GAMALBH-AAT be used in sourcing?

The catalog status is Last-time buy (catalog). For MTFC8GAMALBH-AAT, confirm current lifecycle and exact order-code availability. This catalog status is not a manufacturer longevity or stock guarantee. Verify change notices before a production commitment.

ICLee catalog record

Technical references

MTFC8GAM manufacturer datasheet · 1, 2

MTFC8GAMALBH-AAT

Specifications

Type Description
Catalog lifecycle Last-time buy (catalog)
Grade Automotive (catalog)
Mounting type Surface mount
Operating temperature -40°C ~ 105°C (TA)
Package / case 153-TFBGA
Supply voltage VCC: 2.7–3.6 V; VCCQ: 1.70–1.95 V / 2.7–3.6 V
Supplier device package 153-TFBGA (11.5x13)
Technology NAND Flash — managed eMMC
Memory type Non-volatile
Memory format FLASH
Capacity 64Gbit
Organization 8G x 8
Interface eMMC 5.1 (HS200 / HS400)
Write-cycle time: word / page -
MTFC8GAMALBH-AAT

Features

  • eMMC device combining an MMC controller and NAND Flash, JEDEC/MMC standard version 5.1-compliant (JESD84-B51), with an advanced 12-signal interface and x1, x4, and x8 I/Os selectable by host.
  • e.MMC I/F boot frequency 0 to 52 MHz and e.MMC I/F clock frequency 0 to 200 MHz, supporting HS200/HS400 mode.
  • VCC 2.7-3.6V and VCCQ dual voltage 1.70-1.95V; 2.7-3.6V.
  • TFBGA-153 package.
  • Supports command queue, BKOPS control, temporary write protection, high-speed boot operation, sleep mode, replay-protected memory block (RPMB), and hardware reset signal.
MTFC8GAMALBH-AAT

Applications

  • Embedded boot and operating system storage in eMMC-based designs
  • Firmware and application code storage for embedded processors
  • Data logging and parameter storage in embedded systems
  • Mass storage for handheld and portable electronic devices
